Machining accuracy
Typically ±0.001 mm – ±0.01 mm; some micro-nano work reaches sub-micron levels
Micron-level CNC cutting, forming, and finishing for aerospace, medical, and automotive electronics requirements.
Precision Machining Services use high-precision CNC machine tools and related equipment to cut, form, and finish metals, plastics, and other materials at micrometer-level accuracy — meeting stringent requirements for dimensional accuracy, surface quality, and material performance in aerospace, medical devices, automotive electronics, and similar industries.
What sets precision machining apart from ordinary machining is the precision grade and process control:
Typically ±0.001 mm – ±0.01 mm; some micro-nano work reaches sub-micron levels
Mirror finishes down to Ra ≤ 0.05 μm
Full-process SPC, CMM inspection, and CPK monitoring
Often aligned with ISO 9001, IATF 16949 (auto), ISO 13485 (medical)
Precision machining is not a single process — it integrates multiple methods:
| Process | Characteristics | Typical Applications |
|---|---|---|
| CNC milling | Tool rotates; 3/4/5-axis motion | Complex housings, mold cavities, aerospace structures |
| CNC turning | Workpiece rotates; shafts and rotational parts | Precision shafts, sleeves, threaded parts |
| Turn-mill | Turning + milling in one setup | Complex parts with eccentric holes and keyways |
| Swiss-type | Guide-bush support for slender micro parts | Bone screws, connector pins, micro shafts |
| Precision grinding | Wheel finishing for extreme surface quality | Gages, bearings, precision flats |
| Wire EDM | Electrical discharge cutting for ultra-hard materials | Mold inserts, microstructures |
| High-speed machining (HSM) | High spindle speed and high surface speed | Optical molds, thin-wall parts |
| Micro-nano machining | Feature structures at 0.05–0.3 mm scale | Micro-hole filters, VCM springs, precision sensors |
| Metric | Conventional precision | Ultra-high precision |
|---|---|---|
| Dimensional tolerance | ±0.005 mm – ±0.01 mm | ±0.001 mm – ±0.002 mm |
| Surface roughness | Ra 0.4 – 1.6 μm | Ra ≤ 0.05 μm (mirror) |
| Positional tolerance | ≤ 0.02 mm | ≤ 0.005 mm |
| Flatness | 0.01 – 0.05 mm | Within 0.005 mm |
| CPK | ≥ 1.33 | ≥ 1.67 |
| Inspection equipment | CMM | Zeiss / Hexagon CMM (≈ 0.0015 mm class) |
Suppliers offering injection molding + machining + elastomer assembly see ~23% higher order acceptance than average — one-stop sourcing is rising.
In 2025, specialized CNC purchases were ~56% of industry equipment investment (+19 pp vs 2023). Custom machines (horizontal mill-bore, gantry 5-axis) are replacing general machining centers.
Stable capability on titanium, Inconel 718, and hard HRC60 materials supports quotation premiums of about 18–25%.
Consumer electronics, micro pumps/valves, and wearables drive demand for 0.05–0.3 mm features. Shops that manage etch + stamp + finish in-house respond over 40% faster.
| Industry | Typical Parts | Key Requirements |
|---|---|---|
| Aerospace | Turbine blades, blisks, structural frames | Titanium, 5-axis, AS9100 |
| Medical devices | Bone screws, surgical instruments, implants | ISO 13485, biocompatibility, micro-machining |
| Automotive electronics | Precision valve bodies, motor housings, connectors | IATF 16949, CPK ≥ 1.33 |
| 3C electronics | Phone mid-frames, precision connector housings | High consistency, fast delivery |
| Energy | Wind gearbox housings, hydraulic valve blocks | Large structures, high reliability |
| Robotics / automation | Joint parts, precision transmission, sensors | Miniature precision, high repeatability |
Use these dimensions to assess a precision machining supplier:
Access to high-end assets such as 5-axis and turn-mill centers; transparent equipment lists
Precision metrology such as CMM and demonstrated CPK control
Certifications such as ISO 9001, IATF 16949, ISO 13485
Proven cases on titanium, Inconel, and other difficult alloys
Prototype lead times, production capacity, and schedule reliability
DFM analysis and process optimization recommendations
Clear acceptance criteria, anomaly response, and rework policies
Have a specific part need (material, tolerance, volume, industry)? Upload your CAD for a quote and process recommendation on AIHFABS.
